1 / 8 2-1/2" Crosby® Screw Pin Anchor Shackle | G-209 - 55 Ton
The 2-1/2" Crosby® Screw Pin Anchor Shackle - G-209 - 55 Ton is part of our Crosby (G-209) -Screw Pin Anchor Shackles line in the Shackles department. It is rated with a working load limit of 121,254 lbs. Construction: Carbon Steel Shackle Alloy Pin with a galvanized finish.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Working Load Limit: 121,254 lbs
- Inside Width: 7.25"
- Mouth Width: 4.12"
- Material: Carbon Steel Shackle Alloy Pin
| SKU | SPAS2-12-CR |
|---|---|
| Shipping weight | 85.8 lbs |
| Working Load Limit (lbs.) | 121254 |
| Safety Factor | 6:1 |
| Inside Width | 7.25" |
| Inside Height | 10.51" |
| Mouth Width | 4.12" |
| Shackle Size | 2-1/2" |
| Pin Size | 2-3/4" |
| Material | Carbon Steel Shackle Alloy Pin |
| Finish | Galvanized |
| Type | Screw Pin Anchor |
| Product Weight | 85.8 lbs. |
| Standards | Meets or exceeds all requirements of ASME B30.26, Federal Specification RR-C-271, & ASTM A148M. |
| Manufacturer Name | Crosby® |
| Brand Part Number | 1018678 |
| Additional Info | WLL (tons): 55 |
