1 / 7 1" x 12" Crosby® Jaw & Jaw Galvanized Turnbuckle - HG-228 | 1032812
The 1" x 12" Crosby® Jaw & Jaw Galvanized Turnbuckle - HG-228 - 1032812 is part of our Crosby Galvanized Jaw & Jaw line in the Turnbuckles department. It is rated with a working load limit of 10,000 lbs. Construction: galvanized finish.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Working Load Limit: 10,000 lbs
- Length Closed: 27.18"
- Length Open: 39.18"
- Body Length: 12"
- Diameter: 1"
| SKU | JJTBGV1X12-CR |
|---|---|
| Shipping weight | 12.5 lbs |
| Working Load Limit (lbs.) | 10000 |
| Safety Factor | 5:1 |
| Rated for Overhead Lifting | Yes |
| Diameter | 1" |
| Length Closed | 27.18" |
| Length Open | 39.18" |
| Body Length | 12" |
| Jaw Opening | 1.34" |
| Turnbuckle Size | 1" x 12" |
| Pin Size | 0.88" |
| Finish | Galvanized |
| Product Weight | 12.5 lbs. |
| Standards | Meets or exceeds all requirements of ASTM F-1145 & ASME B30.26. |
| Manufacturer Name | Crosby® |
| Brand Part Number | 1032812 |
| Additional Info | Made in America Jaw end fitted with pins & cotters. |
