1 / 8 4" Low Profile Weld-On Flatbed Winch
The 4" Low Profile Weld-On Flatbed Winch is part of our 4" Winches line in the Winches & Winch Bars department. It is rated with a working load limit of 5,500 lbs. and a break strength of 16,500 lbs. Construction: Steel with a black painted finish.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Working Load Limit: 5,500 lbs
- Assembly Break Strength: 16,500 lbs.
- Width: 7.71"
- Length: 3.93"
- Material: Steel
| SKU | TW412 |
|---|---|
| Shipping weight | 8 lbs |
| Working Load Limit (lbs.) | 5500 |
| Assembly Break Strength | 16,500 lbs. |
| Width | 7.71" |
| Length | 3.93" |
| Height | 4.29" |
| Material | Steel |
| Finish | Black Painted |
| Style | Weld-On |
| Type | Side Mount |
| Product Weight | 7.3 lbs. |
| Additional Info | Can store up to 15' of 4" webbing. |
