1 / 7 5/16" Ratchet Binder
The 5/16" Ratchet Binder is part of our Ratchet Binders line in the Chains & Binders department. It is rated with a working load limit of 5,400 lbs. and a Grade 70 / 80 rating. Construction: Forged Steel with a powder coated finish.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Working Load Limit: 5,400 lbs
- Grade: 70 / 80
- Chain Size: 5/16"
- Length Closed: 22.64"
- Length Open: 28.94"
- Material: Forged Steel
| SKU | CB150 |
|---|---|
| Shipping weight | 10.3 lbs |
| Working Load Limit (lbs.) | 5400 |
| Grade | 70 / 80 |
| Length Closed | 22.64" |
| Length Open | 28.94" |
| Chain Size | 5/16" |
| End Fitting | Clevis Grab Hook |
| Ratchet Handle | Standard |
| Material | Forged Steel |
| Finish | Powder Coated |
| Color | Red |
| Type | Ratchet |
| Product Weight | 10.3 lbs. |
| Standards | FMCSA / DOT compliant and meet or exceed WSTDA T-6 Recommended Standards |
| Quantity | Single |
| Additional Info | Handle length: 15.24" Take up: 6" Hook Throat Opening: .5" |
Shipping
Most orders ship by ground parcel; orders over 150 lbs ship by LTL truck freight with liftgate service. Shipping is calculated at checkout from the actual weight of your order. Full shipping policy.
Returns
This item is final sale. Load-bearing safety equipment can't be resold once it has left our control, so it can't be returned. If it arrives damaged or incorrect, contact us within 7 days and we'll make it right.
