Straightpoint® 1 T Loadlink Plus - LLP1T
$3,514.39
Load Capacity2,200 lbs.
In stock — ready to ship
Pay by ACH or wire — invoice emailed
Parcel or LTL freight, all 50 states
The Straightpoint® 1 T Loadlink Plus - LLP1T is part of our Tension Load Cells line in the Load Cells department.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Load Capacity: 2,200 lbs.
| SKU | LLP-1-T |
|---|---|
| Shipping weight | 3.3 lbs |
| Safety Factor | 12:1 |
| Load Capacity | 2,200 lbs. |
| Pin Size | 3/4" |
| Type | Standard Load Cell |
| Power Source | 9v PP3 battery |
| Accuracy | +/- 0.1% of Full Scale |
| Resolution | 1 lbs. |
| Operating Temperature | -10° to +50°C | 14° to 122° F |
| Battery Life | 80 hours continuous |
| Display Type | 6 digit 1" LCD |
| Product Weight | 3.3 lbs. |
| Standards | IP65 |
| Manufacturer Name | Crosby Straightpoint |
| Brand Part Number | LLP1T / 2789042 |
