Straightpoint® 25 T Compound Plus - CP25T
$6,433.39
Load Capacity55,000 lbs.
In stock — ready to ship
Pay by ACH or wire — invoice emailed
Parcel or LTL freight, all 50 states
The Straightpoint® 25 T Compound Plus - CP25T is part of our Tension Load Cells line in the Load Cells department.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Load Capacity: 55,000 lbs.
| SKU | CP-25-T |
|---|---|
| Shipping weight | 18 lbs |
| Safety Factor | 5:1 |
| Load Capacity | 55,000 lbs. |
| Pin Size | 2" |
| Type | Standard Load Cell |
| Output | Handheld |
| Power Source | 4 x AA Alkaline Batteries |
| Accuracy | +/- 0.1% of Full Scale |
| Resolution | 10 lbs. |
| Range | 3,280' |
| Data Rate | 3Hz - up to 200Hz can be ordered for dynamic load monitorning applications |
| Operating Temperature | -10° to +50°C | 14° to 122° F |
| Battery Life | 1,200 hours continuous |
| Display Type | 240x128 Multi-Line Dot Matrix with Backlight |
| Product Weight | 18 lbs. |
| Standards | IP67 |
| Manufacturer Name | Crosby Straightpoint |
| Brand Part Number | CP25T / 2789021 |
