Straightpoint® 250 T Compound Plus - Bluetooth Enabled - CP250T
$59,120.26
Load Capacity550,000 lbs.
In stock — ready to ship
No payment online — we contact you to arrange payment
Parcel or LTL freight, all 50 states
The Straightpoint® 250 T Compound Plus - Bluetooth Enabled - CP250T is part of our Tension Load Cells line in the Load Cells department.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Load Capacity: 550,000 lbs.
| SKU | CP-BLE-250-T |
|---|---|
| Shipping weight | 209 lbs |
| Safety Factor | 4:1 |
| Load Capacity | 550,000 lbs. |
| Pin Size | 5" |
| Type | Standard Load Cell |
| Output | Bluetooth |
| Power Source | 4 x AA Alkaline Batteries |
| Accuracy | +/- 0.1% of Full Scale |
| Resolution | 200 lbs. |
| Range | 328' |
| Data Rate | 3Hz - up to 200Hz can be ordered for dynamic load monitorning applications |
| Operating Temperature | -10° to +50°C | 14° to 122° F |
| Battery Life | 500 hours continuous |
| Display Type | 240x128 Multi-Line Dot Matrix with Backlight |
| Product Weight | 209 lbs. |
| Standards | IP67 |
| Manufacturer Name | Crosby Straightpoint |
| Brand Part Number | CP250T-BLE / 2789007 |
