Crosby® 7/8" Jaw End Swivel - G-403
The Crosby® 7/8" Jaw End Swivel - G-403 is part of our Crosby G-403 Jaw & Eye Swivel line in the Connecting Links department. It is rated with a working load limit of 10,000 lbs. and a break strength of 50,000 lbs. Construction: hot dip galvanized finish.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Working Load Limit: 10,000 lbs
- Assembly Break Strength: 50,000 lbs.
- Diameter: 7/8"
| SKU | JESWIVEL78-CR |
|---|---|
| Shipping weight | 5.87 lbs |
| Working Load Limit (lbs.) | 10000 |
| Assembly Break Strength | 50,000 lbs. |
| Safety Factor | 5:1 |
| Diameter | 7/8" |
| Finish | Hot Dip Galvanized |
| Product Weight | 5.87 lbs. |
| Standards | Meets or exceeds ASTM A957 & ASME B30.26 requirements. |
| Manufacturer Name | Crosby® |
| Brand Part Number | 1016518 |
Shipping
Most orders ship by ground parcel; orders over 150 lbs ship by LTL truck freight with liftgate service. Shipping is calculated at checkout from the actual weight of your order. Full shipping policy.
Returns
This item is final sale. Load-bearing safety equipment can't be resold once it has left our control, so it can't be returned. If it arrives damaged or incorrect, contact us within 7 days and we'll make it right.
